Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation

Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation

  • High Light

    centrifuge filtration systems

    ,

    bag lifting centrifuge

  • Typ maszyny
    Odśrodkowe samoczyszczące się separatory tarczowe
  • Automatyczny stopień
    Całkowicie automatyczny
  • Fazy
    2 fazy
  • typu
    Odwadnianie alg
  • Separacja
    Oddzielanie ciał stałych od cieczy
  • Rodzaj produktu
    Sprzęt separacyjny
  • Sanitarnych stopnia
    GMP
  • Łożysko
    SKF
  • Materiał miski
    0Cr13 lub DSS
  • Operacja
    Łatwy i wygodny
  • Place of Origin
    China
  • Nazwa handlowa
    Peony
  • Orzecznictwo
    ISO9001&ISO14001,CE
  • Model Number
    PDSM20000-CN
  • Minimum Order Quantity
    1
  • Packaging Details
    Standard export packing
  • Delivery Time
    45days
  • Payment Terms
    TT. LC
  • Supply Ability
    100sets per month

Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation

Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation





Brief introduction



1.Model PDSM20000-CN separator is the newest generation milk separator, mainly used to clarify of milk.

The model is also used to separate similar material in the industry of juice, beverage, Chinese traditional medicine  and chemical industry etc.



2.The machine adopts automatic control, it has the advantages such as high efficiency, low materiel consumption,  convenient operation and economic maintenance cost. It adopts small piston structure for gaining variable discharging capacity, and PLC control both partly and fully discharging in order to get rid of sediment.



3.The clear liquid is pumped out by centripetal pump, the sludge is discharged automatically and partly.



4.The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibration, safety and security.



5.The design, product and acceptance are conformed to the standard of JB/T8103.3 Disc Separator-Part 3 Milk disc separator;



Drum introduction



The drum body is made of 2507 duplex stainless steel and is suitable for CIP cleaning. Other contacted parts made of superior stainless steel which meets the food degree requirements. Drum has such features by the precise dynamic balance check as small vibration to the machine, long continuous-running time and safe and reliable performance.



Dimensions



Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation 0



Main technical parameters



Discharging type

Variable capacity discharge

Fresh milk capacity

L/h

15000~20000

Impurity in milk after separation

Mg/kg

1

Outlet pressure of clear liquid

  Mpa

≤ 0.2

Motor power

  Kw

22

Net weight

  kg

1580

Gross weight

  kg

1800

Overall dimension (L × W × H)

  mm

1479 × 1289 × 1583

Packing size (L × W × H)

  mm

1900 × 1570 × 2050

  Drum rotational speed

    r/min

5790

  G force

    Fr

>10000

  Drum diameter

    mm

510

  Start mode



Variable frequency starting





Installation notice



1. For maintenance and repair, please leave enough space around the separator when install it.

2. The installation base should be firm and level.

3. All the pipes connecting with the separator should be flexible pipe.

4. The operation water of the separator must be soft water, the pressure of which is between 0.025 and   0.03Mpa.



Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation 1Automatic Milk Centrifuge Separator Machine , Solid And Liquid Separation 2
